1000BASE-BX BiDi SFP TX1310nm/RX1490nm 10km Optical Transceiver Module
SFP-1G-BX10U Cisco Compatible, 1000BASE-BX BiDi SFP TX1310nm/RX1490nm 10km DDM Simplex LC SMF Fiber Optical Transceiver Module #151108
0 Sold 0 Reviews 0 Questions
6.00 8.00

Glsun SFP-1G-BX10U-31/49, SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 10KM transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Compatible Cisco Form Factor SFP
Max Data Rate 1.25Gbps Wavelength TX1310nm/RX1550nm
Max Cable Distance 20km Connector Simplex LC
Transmitter Type 1310nm FP Extinction Ratio 9dB
Media SMF Power Consumption <0.8W
Power Supply Voltage 3.3V Operating Case Temperature 0°C to +70℃ (C); -40°C to +85℃ (I)
