2500BASE-BX BiDi SFP TX1550/RX1310nm 40km DOM LC SMF Fiber Optical Transceiver Module
#151067
20 Sold
2 Reviews
0 Questions
18.72 26.00
PN: SPF-2.5G-BX40D-T02
Ship From China
870 in stock
2500BASE-BX BiDi SFP TX1550/RX1310nm 40km DOM LC SMF Fiber Optical Transceiver Module #151067
20 Sold
2 Reviews
0 Questions
18.72 26.00
GLsun SPF-2.5G-BX40D, SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 2.5Gbps/2.125Gbps and 40km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
| Form Factor | SFP | Max Data Rate | 2.5Gbps |
| Wavelength | 1550nm-TX/1310nm-RX | Max Cable Distance | 40km |
| Connector | Simplex LC | Transmitter Type | 1550nm DFB |
| Extinction Ratio | 9dB | Media | SMF |
| Power Consumption | <0.8W | Power Supply Voltage | 3.3V |
| Operating Case Temperature | 0°C to +70℃ (Commercial); -40°C to +85℃ (Industrial) |
