SFP-10G-CWDM-1570-10 Cisco Compatible, 10GBASE-CWDM SFP+ 1570nm 10km DOM LC SMF Fiber Optical Transceiver Module

#141044
1 Sold 0 Reviews 0 Questions
38.79 72.43
PN: SFP-10G-CWDM-1570-10-T02
Compatible
Cisco
Transceiver Type
1470nm
1490nm
1510nm
1530nm
1550nm
1570nm
1590nm
1610nm
Distance
40km
80km
Ship From China
503 in stock
Add to Cart
SFP-10G-CWDM-1570-10 Optical Transceiver Module
SFP-10G-CWDM-1570-10 Cisco Compatible, 10GBASE-CWDM SFP+ 1570nm 10km DOM LC SMF Fiber Optical Transceiver Module #141044
1 Sold 0 Reviews 0 Questions
Add to Cart
38.79 72.43

GLsun's SFP-10G-CWDM-1570-10 CWDM DFB 10Gbps SFP+ transceiver modules are designed to transmit and receive optical data over single mode optical fiber for link length 10km. This transceiver consists of two sections. The transmitter section incorporates a CWDM DFB laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

Compatible Cisco Form Factor SFP+
Max Data Rate 10.3125Gbps Wavelength 1570nm
Max Cable Distance 10km Connector Duplex LC
Transmitter Type 1570nm DFB Extinction Ratio 5dB
Media SMF Power Consumption <1W
Power Supply Voltage 3.3V Operating Case Temperature 0°C to +70°C (Commercial); -40°C to +85°C (Industrial)
Quality Certifications
Product Spotlights
Quality Testing

Wavelength Testing

Bit Error Rate Testing

Performance Testing

Final Testing

Production Workshop

Download

sfp-10g-cwdm-1570nm-10km-optical-module-141044.pdf
